3 Tons Stainless Steel Ice Sea Maker for Boat Fishing Simple to Operate

1:High refrigeration efficiency: the latest evaporator with vertical spiral ice cutter is adopted. Water is sprayed by the sprinkler on the inner wall of the evaporator, forming ice quickly. At the same time, the spiral cutter cuts the forming ice, which makes full use of the evaporator surface and increases the efficiency of ice making.
2:Space saved: the structure is compact and simple.
3:Full automatically: the whole ice making and droping process are controlled by PLC controller.

Send InquiryChat Now
Product Details

3 tons /24 hours seafood flake ice machine


1. Seafood flake ice machine main features

1:High refrigeration efficiency: the latest evaporator with vertical spiral ice cutter is adopted. Water is sprayed by the sprinkler on the inner wall of the evaporator, forming ice quickly. At the same time, the spiral cutter cuts the forming ice, which makes full use of the evaporator surface and increases the efficiency of ice making.

2:Space saved: the structure is compact and simple.

3:Full automatically: the whole ice making and droping process are controlled by PLC controller.



2. Quick details of flake ice machine

1. Daily capacity: 1 ton to 60 tons per set per 24hrs.

2. Flake ice machine has fresh water type used on land, sea water used on land and sea water flake ice machine used on fishing trawlers.


ice maker for boat

seafood flake ice machine

Flake ice widely used in:Supermarket, food processing enterprises, chain catering, concrete mixing plant, chemical plant.


ice sea maker


ice sea maker for boat fishing


3 ton/24hours ice sea maker for boat fishing Parameters















Working Conditions

Refrigerant

R22/ R404a/R507

Cooling way

Water cooling/Air cooling

Machine size

1800*1500*1360mm

Ambient temp.

+50 ℃

Supply water temp

20 ℃

Evaporating temp.

-20 ℃

Condenser temp.

+40 ℃

Relative humidity

85 %

Noise

55dB





Compressor

Brand Name

Germany Bitzer

Product Model

4NCS-12.2Y(12HP)

Power

9.87 KW

Refrigerating Capacity

18.6 KW









Other electric components

Brand Name

CBFI

Power of Cooling Water Pump

0.37 KW

Power of Reducer

0.09 KW

Power of Condensing water pump

0.75 KW

Power of condensing air cooling fan

0.18KW


ice sea maker simple to operate


ice flake machine

Ice sea maker simple to operate main components brand.

flake ice maker business


Customer cases

●50 tons flake ice machine with Raking System Automatic ice packing in Morocco

●20 Tons Flake Ice Machine with 40 Tons Raking System Automatic ice packing in Mozambique

●20 Tons Flake Ice Machine with screw automatic ice packing in Qatar for Concrete cooling

●2 sets of 10 Tons flake ice machine in Maldives


commercial flake ice maker


For more details of the flake ice machine, pls click here to check.
