5 Tons Automatic Edible Ice Tube Maker Machine Price for Bars and Hotels

1,Specail compressor protecting device: CBFI self-developed oil balance system makes sure lack of oil to compressor when it running. 2, Automatic discharging outlet :(save labor and guarantee sanitary )Which can help save lot of labor cost when doing the ice business 3,Sanitary and safe ice: Ice making water contacting parts are all adopting edible grade SUS304 and PVC material.

Send InquiryChat Now
Product Details

5 Tons Automatic Edible Ice Tube Maker Machine Price For Bars And Hotels



1, Specail compressor protecting device of ice tube machine:CBFI self-developed oil balance system makes sure lack of oil to compressor when it running.

2, Ice tube machine price of automatic discharging outlet:(save labor and guarantee sanitary )Which can help save lot of labor cost when doing the ice business.ice tube maker machine price and the labor cost will reduce your pre-cost.

3,Sanitary and safe ice: Ice making water contacting parts are all adopting edible grade SUS304 and PVC material.

4,Ice tube machine price of Long life span: The tube we will import the Japan 304 SUS Seamless steel pipe,which can at least use for 20years.

5, Tube ice size : 22mm, 28mm, 35mm for option , the length of the tube ice can be designed as customer need.

6,Ice tube machine price Space-saved: machine unit adopt 3D model, reasonable layout, integerated design, the structure is very compact. With the ice tube maker machine price is more Competitiveness.


Tube ice of tube ice machine for drink cooling

ice tube maker machine price


Nice tube ice

ice tube machine for bars


5 tons / 24hours Automatic Edible Ice Tube Maker Machine Price TV50

5 tons ice tube machine

All in one design tube ice machine price


edible ice tube machine

5 ton per day tube ice machine in the factory


5 tons / 24hours Automatic Edible Ice Tube Maker Machine feature

automatic edible ice tube machine


The above picture of ice tube machine:

1,Automatic tube ice out let of ice tube maker machine: make the tube ice come out automatic.

2,PLC controller of the ice tube machine: we use German Siemens PLC controller to control the ice machine automatic , the ice machine only need 2 people operate ( one people to pack the ice , one people to put the ice into cold storage)

3,Japan 304 SUS Seamless steel pipe: make the ice more clean and make sure the machine have longer life span

4,Different ice size : 22mm , 28mm and 35mm , you can choose the most popular ice size for your local market.


5 tons / 24hours Automatic Edible Ice Tube Maker Machine Application

Tube ice machine

The tube ice widly use in the food cooling and drink shop , and the party .

Also in the resturant , hotel , surper market .

Now the tube ice has been a fatory production and distribute to the store .


5 tons / 24hours Automatic Edible Ice Tube Maker Machine parameters

Working condition

Power supply

380v/50Hz/3phase , 380v/60Hz/3phase ,
220v/50Hz/3phase, 220v/60Hz/3phase

Refrigerant

R22 / R 404a

Cooling way

Water cooling / Air cooling

Max. Ambient temp.

+45 ℃

Supply water temp

23 ℃

Evaporating temp.

-12 ℃

Condenser temp.

+40 ℃

Relative humidity

85 %

Noise

55dB


Compressor

Brand Name

Bitzer (From Germany)

Type

Semi-Hermetic Piston type

Product Model

6HE-28 (25HP)

Power

21kw

Refrigerating Capacity

60.2 kw

Cooling Tower

Brand Name

CBFI

Size

Φ1615*1890 mm

Power of Cooling Water Pump

2.2 kw

Power of Cooling Fan

0.55 kw

Cooling Water Consumption

0.05 m3/h

Ice making water Circulating pump

Brand Name

Nanfang

Power

1.5 kw

Ice Cutter Motor

Brand Name

Rador

Power

0.75 kw


5 tons / 24hours Automatic Edible Ice Tube Maker Machine Main components

Item No.

Name of Components

Brand Name

1

Compressor

Germany Bitzer

2

PLC

Germany SIMENS

3

Expansion valve

Denmark DANFOSS

4

Solenoid valve of Water supply

Denmark DANFOSS

5

Oil filter

America Emerson

6

High and low pressure meter

Switzerland REFCO

7

Electrical components

South Korea LG (LS)

8

Circulating water pump

China Nan Fang

9

Evaporator Material

Stainless Steel 304 (SUS304)


Supporting equipment of the ice tube machine price( As the following picture show)


1,Cold room: for ice storage , make sure the ice can last for longer time

2,Digital scale : make each bags with same kg

3,Bag sealer : sealing the ice bag

4,Ice bin : easy for the ice packing

5 tons automatic edible ice tube maker machine



Tube ice machine production at our factory


 automatic edible ice tube maker machine


FAQ

Q1: What configuration of the voltage of the machine is ?

A: We adopt standard voltage -380V/3P/50Hz usually, non-standard voltage can be customized, the price is extra.

Q2: What’s your usual practice about terms of payment ?

A:The payment can be T/T,L/C,Western Union, Money Gram and in Cash.

The deposit is 30%, after we receive your deposit, we will start to produce the machine for you.

The balance 70% should be paid before shipping.

Q3: How long is the time of delivery?

A: The delivery time normally is 30 days after we receive the deposit.

If necessary, we will arrange the shipping for you.


For more detail please click : CBFI 1 ton to 30 ton tube ice machine specification
