This equipment adopts food grade aluminum alloy evaporator direct refrigeration technology, combined with safety standards and efficient ice making efficiency. Its working principle is to introduce water into the evaporator through a mold for freezing and forming. Unlike the traditional multi-faceted freezing mode of saltwater systems, this model has a unique bottom single-sided refrigeration process. Although the ice formation rate is at a moderate level, the produced ice cubes have the following core advantages: crystal clear intrinsic quality, zero bubble structure, excellent compressive strength, regular geometric shape and no central groove. This type of high-quality ice can be flexibly processed into ice balls, large-sized ice blocks (suitable for whiskey), ice sculptures, and other forms, fully meeting the needs of high-end beverages and scenario based applications.
Core advantages of pure ice machine
● Applying cutting-edge transparent ice making technology, the operation is simple and the equipment structure is stable, which can effectively reduce the later operation and maintenance costs and ensure long-term stable operation.
● The ice body exhibits full transparency and no hollow grooves, with a material utilization rate of up to 100%, significantly improving cost-effectiveness.
● Under the premise of meeting water quality standards, the produced transparent ice fully complies with food grade safety regulations and is suitable for various beverages and consumption scenarios.
● Compact equipment size facilitates transportation, movement and on-site installation, requiring no excessive space and adapting to various site layouts.
● The compact body design is easy to transport, move, and install on site, with low space occupancy and strong adaptability.
Widely applicable scenarios, covering needs such as celebration events, corporate team building, ceremonial ceremonies, ice sculpture creation, nightclubs, and bars. It can not only enhance the visual and taste experience of high-end drinks, but also support characteristic ice sculpture decoration and theme scene arrangement, with outstanding practical value.
Product Parameter
| PIM-0202 | ||
| Power Supply | 220V/50HZ/1P | |
| Refrigerant | Environmentally Friendly Refrigerant | |
| Evaporating Temperature | ℃ | -23 |
| Condensing Temprature | ℃ | 40 |
| Ambient Temperature | ℃ | 32 |
| Water Supply Temperature | ℃ | 20 |
| Ice Thickness | mm | 250 |
| Ice Size | mm | 1000*500*250 |
| Single Ice Block | Kg | 112.5 |
| Capacity per time | Kg | 225 |
| Quantity of ice per time | piece | 2 |
| Ice Making Time | h | 70 |
| Equipment Size (L*W*H) | mm | 1300*1225*973 |
| Power | kW | 0.66 |
| ♦Compressor Brand: Copeland; Refrigerant: Environmentally Friendly Refrigerant; Cooling Method: Air cooling;
♦ Power Supply: 220V/1P/50Hz; (For non-standard voltage, unit configuration needs to be calculated separately). ♦ Remark: The actual ice production varies due to the influence of water supply temperature and ambient temperature. ♦ Remark: Design and specifications subject to change without notice. |
||
Product Details
● The electronic control system is equipped with multiple circuit protection devices, effectively avoiding faults and ensuring safe and stable equipment operation.
● The whole machine is made of stainless steel material, which combines the advantages of food grade hygiene standards, corrosion resistance, and easy cleaning, and meets the hygiene standards of multiple scenarios.
● Through standardized production lines and strict quality control at every stage, we ensure uniform equipment quality, stable performance, and extremely low failure rates.
